Computer Fan Yellow Wire

What is the function of yellow wire.

Quiet cool whole house fan operating instructions. Fans and on board fan headers are backwards compatible. The answer to your question is no. Simply connect yellow and red to 12v and the fan will run.

If i want to power it with 12v battery where i would connect the yellow wire. Chassis and cpu fans may use either 3 pin or 4 pin power connectors. You dont need it to make the fan turn but the third wire is there for a good reason.

Why there is yellow wire in 12 v pc fan. 4 pin connectors are usually used by cpu fans with higher power consumption. Of course all you need is the red and black wire to run your computer fan but if you didnt know what the extra wires are for this video may help you out.

2 fan with 3 wires black red yellow 3 fan with 4 wires black red yellow blue warning never ever mix yellow blue with red fan will die no repair black ground negative red wire is positive 12v 7v 5v fan only need two wires black red to workat full speed yellow sends fan speed to motherboard. A pc fans wire colors are pretty consistent with red almost invariably marking the positive and black marking the negative or ground. The third wire varies depending on the manufacturer but usually it is blue or yellow.

Depends what the yellow wire is for. If its merely to tell how fast the fan is spinning then no because the yellow wire has no way of setting the resistance it just tells the computer or circit connected to it how fast the fan is going the motherboard or separate fan controller has a variable resistor. Thus instead of using the colors to distinguish the function better try to study the internal wiring connection.

On these 4 wire computer fans i have found that some times they require an input to tell it how fast to spin so simply supplying power to 2 of the wires will not work if you have a 3 wire fan however you can supply power to the red and black and leave the white disconnected. 3 pin connectors are usually used for the smaller chassis fans with lower power consumption.
